Шлифованные прутки с фаской в дюймах
|
Тип |
ØD |
l Допуск/0,+1/16 |
Размер фаски |
|
|
Фаска |
Допуск |
|||
|
BR2031038 |
1/8 |
1-1/2 |
0.015 |
±0.004 |
|
BR2031050 |
1/8 |
2 |
0.015 |
±0.004 |
|
BR2031063 |
1/8 |
2-1/2 |
0.015 |
±0.004 |
|
BR2031076 |
1/8 |
3 |
0.015 |
±0.004 |
|
BR2047050 |
3/16 |
2 |
0.015 |
±0.004 |
|
BR2047076 |
3/16 |
3 |
0.015 |
±0.004 |
|
BR2063050 |
1/4 |
2 |
0.015 |
±0.004 |
|
BR2063063 |
1/4 |
2-1/2 |
0.015 |
±0.004 |
|
BR2063076 |
1/4 |
3 |
0.015 |
±0.004 |
|
BR2063101 |
1/4 |
4 |
0.015 |
±0.004 |
|
BR2079063 |
5/16 |
2-1/2 |
0.015 |
±0.004 |
|
BR2095063 |
3/8 |
2-1/2 |
0.015 |
±0.004 |
|
BR2095076 |
3/8 |
3 |
0.015 |
±0.004 |
|
BR2127063 |
1/2 |
2-1/2 |
0.031 |
±0.008 |
|
BR2127076 |
1/2 |
3 |
0.031 |
±0.008 |
|
BR2127101 |
1/2 |
4 |
0.031 |
±0.008 |
|
BR2158088 |
5/8 |
3-1/2 |
0.031 |
±0.008 |
|
BR2190101 |
3/4 |
4 |
0.031 |
±0.008 |
|
BR2190127 |
3/4 |
5 |
0.031 |
±0.008 |
|
BR2254101 |
1 |
4 |
0.031 |
±0.008 |
|
GESAC Стандарт GESAC |
Шлифованный диаметр (дюйм) |
Угол фаски (°) |
||
|
Диапазон |
Допуск |
Допуск |
||
|
0.0125≤ØD≤1.25
|
h5 |
h6 |
СО +1 LO |
|
